Home //DVR // CP-UVR-1601E1-IC 16Ch. 1080N Digital Video Recorder
CP-UVR-1601E1-IC 16Ch. 1080N Digital Video Recorder(excl. of all taxes)
2 Reviews
CP PLUS
Check delivery
₹7,49918% GST will be applied at checkout
₹8,29910% Off14In-Stock
Available offers
Special Price Get extra 37% off T&C
Bank Offer Flat ₹75 cashback on a minimum order value of ₹99
Bank Offer 5% cashback on Axis Bank Credit Card up to ₹750 T&C
24x7 Support
Easy Return
100% Original
Make In India
Specifications
| Processor | Embedded processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 16+2: each channel up to 6MP Two-way Talk Reuse audio in/out, RCA |
| User Interface | GUI |
| SMD Plus Performance | 8 channels |
| AI Search | Search by target classification (Human, Vehicle) |
| Video Input | 16 channel, BNC |
| Video Output | 1 HDMI, 1 VGA |
| Compression AI | Instastream/Instastream/H.265/H.264+/H.264 |
| Video Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Resolution | 1080N; 720P; 960H; D1; HD1; BCIF; CIF; QCIF |
| Video Recording | Main Stream: the 1st channel 1080N/720P (1 fps–25/30 fps), others 1080N/720P (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps) |
| Video Display | Split 1/4/8/9/16 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Bit Rate | 32 kbps–4096 kbps per channel |
| Audio Input | 1 channel RCA 16-channel BNC (Coaxial Audio) |
| Audio Output | 1 channel, RCA |
| Motion Detection | Support |
| Video Loss | Support |
| Audio Compression | G.711A, G.711U, PCM |
| Camera Blank | Support |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature. |
| Audio Sample Rate | 8KHz, 16 bit Per ChanneL |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Playback | 1/4/9/16 Ch. |
| Recording Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Playback | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom |
| Backup Mode | USB Device/Network |
| Interface Ports | 2 USB Ports (2.0) |
| Max User Account | 128 users Record Interval 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec Ethernet 1 (10/100 Mbps Ethernet port, RJ-45) |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; InstaOn Cloud, ONVIF 21.06; CGI Conformant Power Supply DC12V/2A Power Consumption <10W(without HDD) |
| Working Temp | -10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% RH Dimensions 260mm x 236mm x 48mm |
| Weight | 0.89kg (without HDD) |
Product Details
• Auto Adaptive HDCVI/AHD/TVI/CVBS/IP signals
• Max 18 channels IP camera inputs, each channel up to 6MP
• Max 64Mbps Incoming Bandwidth
• Instastream/H.265 dual-stream Video Compression
• Support 1 SATA HDD up to 16TB, 2 USB Ports
• Up to 8 channels video stream (analog channel) SMD Plus
• HDMI / VGA Simultaneous Video Output
• Mobile Software: iCMOB, gCMOB
• CMS Software: KVMS Pro
