CP-UVR-0808E1-I 8Ch. 1080N Digital Video Recorder(excl. of all taxes)

2 Reviews

CP PLUS

Check delivery

₹3,78618% GST will be applied at checkout

₹7,50050% Off

In-Stock

Available offers

Special Price Get extra 37% off T&C

Bank Offer Flat ₹75 cashback on a minimum order value of ₹99

Bank Offer 5% cashback on Axis Bank Credit Card up to ₹750 T&C

24x7 Support

Easy Return

100% Original

Make In India

Specifications

Processor	Industrial-grade processor
Operating System	Embedded Linux
Analog Camera Input	BNC ports, supports HDCVI/AHD/TVI/CVBS autodetect
IP Camera Input	Up to 10 channels of IPC access 2 IP channels by default + 8 channels (analog channels are converted to IP channels) Incoming bandwidth: 40 Mbps, recording bandwidth: 40 Mbps and outgoing bandwidth: 40 Mbps *After IP extension is enabled, the AI Function (SMD) will be disabled.
Two-way Talk	Coaxial two-way talk: 8 Channel BNC Local and network user two-way talk: Shares the same audio input with the first channel
User Interface	Web, Local GUI
Video Output	1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Abnormality Alarm	Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline
SMD By Camera	10 Channels
Camera Input	1. CVI: 1080p@25/30 fps; 720p@25/30 fps. 2. TVI: 1080p@25/30 fps; 720p@25/30 fps. 3. AHD: 1080p@25/30 fps; 720p@25/30 fps
stream Capability	Dual stream
Video Frame Rate	Main stream: The 1st channel 1080N/720p@(1 fps–25/30 fps), others 1080N/720p@(1 fps–15 fps), 960H/D1/CIF@(1 fps–25/30 fps) Sub stream: CIF@(1 fps–7 fps)
Video Display Split	When IP extension mode not enabled: 1/4/8 When IP extension mode enabled: 1/4/8/9/16
Record Mode	General, Alarm, Motion detection
Bit Rate	32 kbps–4096 kbps
Video Compression	AI Coding, Instastream, H.265, H.264+, H.264
Protocols	HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
Audio Input	1-channel RCA, 8 Channel BNC (Coaxial Audio)
SMD Plus by DVR	Channels: Secondary filtering for human and vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change
Disk Interface	1 SATA port, up to 6 TB. This limit varies depending on the environment temperature
Browser	Chrome, IE, Safari, Edge, Firefox
Recording Playback	1/4/
Backup Mode	USB device and network
Interface Ports	2 USB (2 rear USB 2.0 ports)
Ethernet	1 (10/100 Mbps Ethernet port, RJ-45)
Power Supply	12 VDC, 1.5
Power Consumption	<7 W (without HDD)
Operating Temperature	–10°C to +45°C (+14°F to +113°F)
Operating Humidity	10%–90% (RH), non-condensing
Storage Temperature	–10°C to +45°C (+14°F to +113°F)
Dimension	197.0 mm × 204.3 mm × 41.5 mm

Product Details

Supports HDCVI, AHD, TVI, CVBS and IP video input
Supports up to 10-channel IP camera input and each channel can be up to 6 MP.
The incoming bandwidth reaches 40 Mbps
8 Channel two-way talk over coaxial cable allows for seamless communication between the camera, client and recorder
Instastream, H.265, H.264+ H.264 dual-stream video compression
Mobile Software: iCMOB, gCMOB
