CP-UVR-0401F1-IC 4Ch. 5M-N Digital Video Recorder(excl. of all taxes)

2 Reviews

CP PLUS

Check delivery

₹3,87618% GST will be applied at checkout

₹5,80033% Off

In-Stock

Available offers

Special Price Get extra 37% off T&C

Bank Offer Flat ₹75 cashback on a minimum order value of ₹99

Bank Offer 5% cashback on Axis Bank Credit Card up to ₹750 T&C

24x7 Support

Easy Return

100% Original

Make In India

Specifications

Processor	Embedded processor
Operating System	Embedded LINUX
IP Camera Input	4+2 channels, each channel up to 6MP
Two-way Talk	Reuse audio in/out, RCA
User Interface	GUI
Performance SMD Plus	4 Channels
AI Search SMD	Search by target classification (Human, Vehicle)
Video Input	4 channel, BNC
Video Output	1 HDMI, 1 VGA
Video Compression	Instastream/H.265+/H.265/H.264+/H.264
Video Resolution	1920×1080, 1280×1024, 1280×720
Resolution	5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
Video Recording	Main stream: All channel 5M-N (1 fps–10 fps); 4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/ D1/CIF (1 fps–25/30 fps) Sub stream: D1/CIF (1 fps–15 fps)
Video Display Split	1/4
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Bit Rate	32 kbps–6144 kbps per channel
Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Audio Sample Rate	8KHz, 16 bit Per Channel
Audio Bit Rate	64Kbps Per Channel
Motion Detection	Support
Video Loss	Support
Audio Compression	G.711A, G.711U, PCM
Camera Blank	Support
Smart Phone	iPhone, iPad, Android Phone
Hard Disk	1 SATA port, up to 6TB Each
Alarm Input	N/A
Alarm Output	N/A
Trigger Events	Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Playback	1/4 Ch.
Recording Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second)
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
Backup Mode	USB Device/Network
Interface Ports	2 USB Ports (USB 2.0)
Max User Account	128 users
Record Interval	1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Ethernet	1 RJ-45 port (100Mbps)
Protocols	HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wi-Fi; 3G/4G; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; InstaOn; IP Search, ONVIF 16.12, CGI Conformant
Power Supply	DC12V/1.5A
Power Consumption	<4W (without HDD)
Working Temp	-10°C ~ +45°C (+14°F ~ +113°F), 0 ~ 90% (RH)
Dimension	198 mm × 203.0 mm × 41.5 mm
Weight	0.55kg (without HDD)

Product Details

Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 6 channels IP camera inputs, each channel up to 6MP; Max 32Mbps Incoming Bandwidth
Supports Full-channel AI-Coding
Support 1 SATA HDD up to 6TB Each, 2 USB Ports
Up to 4 channels video stream (analog channel) SMD Plus.
1 HDMI / 1 VGA Simultaneous Video Output
Instastream/H.265 dual-stream video compression
Mobile Software: iCMOB, gCMOB
CMS Software: KVMS Pro Lite
