CP-DPS-PD04V3-12D 4 Channel Power Supply(excl. of all taxes)

2 Reviews

CP PLUS

Check delivery

₹48718% GST will be applied at checkout

₹90046% Off

In-Stock

Special Price Get extra 37% off T&C

Bank Offer Flat ₹75 cashback on a minimum order value of ₹99

Bank Offer 5% cashback on Axis Bank Credit Card up to ₹750 T&C

24x7 Support

Easy Return

100% Original

Make In India

Input voltage	200 ~ 240VAC
Input AC Frequency Range	47 ~ 63Hz
Input Current (Typ.)	0.5A/230VAC
Power Cord	2 Pin (L & N)
Standby Power Consumption	≤0.5W
Inrush Current (Typ.)	≤40A@230VAC
Efficiency (Typ.)	85%
Output voltage	12V in Normal Mode
Output Current	3.0A in Normal Mode
Output Current range	0 ~ 3.0A in Normal Mode
Rated Power	36W in Normal Mode
Ripple & Noise (max.)	≤240mV
Line Regulation	2%
Load Regulation	3%
Power On Indicator	Support
Cable Compensation Switch	Support, 3 Modes (Normal, Long, Ex. Long)
No. of Output Ports	Single Port
short-circuit protection	Support
Dielectric Strength (Hi-pot)	3.0KV
Insulation Resistance	100MΩ@500VDC
Surge Immunity	1.0KV
Operating Temperature	-10 ~ +45°C
Operating Humidity	20 ~ 90% RH Non-condensing
Storage Temperature	-10 ~ +45°C
Storage Humidity	10 ~ 95% RH
Dimension	132.7mm x 77.7mm x 33.2mm
Weight	0.144kg without Power Cord and Packing Box
